Little Giant Water Wizard Submersible Pump 505486

LITTLE GIANT Water Wizard Submersible Pump 505486

LITTLE GIANT Water Wizard Submersible Pump



Little Giant 505486 Water Wizard Submersible Pump

  • Motor – 1/6HP Shaded Pole
  • Maximum flow rate – 1200 GPH @ 1′, 4542 LPH @ 30 cm.115V, 60Hz, 5 amps
  • Maximum Head – 26.3″…8 m
  • Intermittent Liquid Temp to – 120° F….49° C
  • Epoxy-coated aluminum housing
  • Operates submersed1″FNPT (25.4 mm) discharge
  • 1″ FNPT outlet includes garden-hose adapter, bottom inlet has removable screen for easy cleaning

Little Giant 1/4 Horsepower Sump Pump 505700

LITTLE GIANT 1/4 Hp Sump Pump 505700

LITTLE GIANT 1/4 Hp Sump Pump



Little Giant 505700 1/4 Horsepower Sump Pump

  • 1/4 HP
  • 1-1/4″ FNPT outlet with a garden hose adapter
  • 10′ or 25′ length power cords are available
  • Integral snap-action float switch
  • Automatic operation has 7″-10″ .ON. level range and 2″-5″ .OFF. level range
  • Thermally protected3/8″ solid handling capacity

Little Giant Drainosaur Water Pump System 506055

LITTLE GIANT Drainosaur Water Pump System 506055

Little Giant 506055 Drainosaur Water Pump System

  • Pump made of cast iron housing with protective epoxy coating for corrosion resistance
  • Screened intake
  • 1/3 HP motor with thermal overload protection
  • Automatic diaphragm pressure switch enclosed in nylon housing with .on. level at 7″.10″ and .off. level at 1″.4″
  • Basin made of polypropylene

Little Giant Big John Sump Pump 506158

LITTLE GIANT Big John Sump Pump 506158

Little Giant 506158 Big John Sump Pump

  • Cast iron pump housing with protective epoxy coating for corrosion resistance
  • Oil-filled motor housing for lifetime lubrication and rapid heat dissipation
  • 1/3 HP shaded pole motor
  • Stainless steel screws, bolts and handle to protect against corrosion
  • Mechanical seal (stainless steel spring, nitrile parts, carbon and ceramic faces) to assure maximum protection against pump failure
  • Bearings: Upper and lower sintered sleeve bearings for extended motor life
  • Thermal overload protection

Little Giant Pit Plus Simplex 509109

little giant simplex system pit plus package

Little Giant 509109 Pit Plus Package with Foam Cover

The Little Giant PitPlus™ comes equipped with a 4/10 HP 9S Series or a 1/2 HP 10S Series wastewater and sewage ejector pump. Both units are equipped with cast iron housings and volutes that have a protective epoxy coating. Automatic operation is achieved by use of a piggyback mechanical float switch.

Features:

  • 4/10 HP 9S Series pump
  • Handles liquid and solid waste materials up to 2″ diameter
  • Larger capacity extends pump life by reducing pump cycles
  • 20″×30″ polyethylene basin with ribs for added strength
  • 4″ molded external inlet hub to accept flexible coupling
  • Molded torque stops in bottom of basin to locate and secure pump
  • Anti-flotation collar
  • Stainless steel cover bolts

Little Giant Simplex Basin 513240

little giant pump simplex base and cover

Little Giant 513240 Simplex Basin and Cover

  • Basins available in molded polyethylene or fiberglass
  • Complete with necessary sealing hardware and flanges
  • Available with 2″ or 3″ vent or discharge flange
  • 4″ inlet hub is included with the basin
  • Water tight and gas tight when properly installed
  • Durable steel gasketed cover standard on fiberglass basin, structural foam cover on poly basin
  • One-piece, seam-free construction on basin
  • Ready-to-install for simple and economical installation
  • Temperature rated up to 130°F

Little Giant 547151 Big John Vertical Sump/Effluent Pump

little giant sump pump

Little Giant 547151 Big John Vertical Sump/Effluent Pump

  • Plastic volute made of corrosion-proof ABS
  • 1-1/4″ FNPT discharge
  • 1/4″ solids handling capability
  • Thermal overload protection
  • Automatic operation with integral snap-action float switch
  • Adjustable on/off levels: on 10″. 5″, off 9″. 4″
  • UL/CSA listed

Little Giant 554200 115V 60Hz Condensate Removal Pump

Little Giant Condensate Pump

Little Giant 554200 115V 60Hz Condensate Removal Pump

  • Low profile compact size
  • Vertical type pump unit
  • Leakproof, rustproof, ABS tank
  • Stainless steel motor shaft
  • 3/8″ O.D. barbed discharge adapter
  • Built-in check valve
  • Safety switch included
  • 20′ shut-off head
  • 6′ power cord
  • UL/CSA listed

Little Giant 554550 Condensation Removal Pump

LITTLE GIANT 115V 60Hz Condensate Removal Pump

Little Giant 554550 Condensation Removal Pump

  • 1/4 turn check valve allows servicing without removal of tubing, eliminating water spills
  • Patent-pending cooling design increases pump life
  • Optional external overflow safety switch, which gives the option to connect air-handler shutdown or activate an alarm or building automation system
  • External test/run lever for quick and easy drainage of tank for servicing
  • Oil-resistant tank and check valve eliminates the problem of cracked tanks with exposure to oil
  • Rubber feet absorb vibration on hard surface installations
  • 1/4 turn check valve allows servicing without removal of tubing, eliminating water spills
  • Patent-pending cooling design increases pump life

Little Giant Pond Waterfall Pump 566407

Little Giant steam waterfall pump

Little Giant 566407  Waterfall/Stream Pump 4300 GPH

4300 GPH* Ideal for use in waterfall and stream applications, this powerful direct-drive pump features a unique dual-discharge design for operation of two water features simultaneously. This pump is extremely versatile, able to be used vertically or horizontally.
